› 5mqw

X-ray diffraction
2.4Å resolution

Function and Biology Details

Biochemical function:
Biological process:
  • not assigned
Cellular component:
  • not assigned
Sequence domain:

Structure analysis Details

Assembly composition:
homo trimer (preferred)
Assembly name:
PDBe Complex ID:
PDB-CPX-174239 (preferred)
Entry contents:
1 distinct polypeptide molecule
Macromolecule:
Polyhedrin Chain: A
Molecule details ›
Chain: A
Length: 248 amino acids
Theoretical weight: 28.3 KDa
Source organism: Operophtera brumata cypovirus 18
Expression system: unidentified baculovirus
UniProt:
  • Canonical: Q30C70 (Residues: 2-248; Coverage: 100%)
Sequence domains: Cypovirus polyhedrin protein

Ligands and Environments

4 bound ligands:
Ligand CL 1 x CL
Ligand GTP 1 x GTP
Ligand ATP 1 x ATP
Ligand MG 1 x MG
No modified residues

Experiments and Validation Details

Entry percentile scores
X-ray source: SLAC LCLS BEAMLINE XPP
Spacegroup: I23
Unit cell:
a: 102.8Å b: 102.8Å c: 102.8Å
α: 90° β: 90° γ: 90°
R-values:
R R work R free
0.114 0.112 0.146
Expression system: unidentified baculovirus

Quick links

Citations

11 review citations

The life cycle of non-polio enteroviruses and how to target it.
Baggen et al. (2018)
10 more

1 mention without citation

High-speed fixed-target serial virus crystallography.
Roedig et al. (2017)
