EMD-40645

Single-particle
3.0 Å
EMD-40645 Deposition: 28/04/2023
Map released: 11/10/2023
Last modified: 11/10/2023
Overview 3D View Sample Experiment Validation Volume Browser Additional data Links
Overview 3D View Sample Experiment Validation Volume Browser Additional data Links

EMD-40645

cytochrome bc1-cbb3 supercomplex from Pseudomonas aeruginosa (Locally refined cytochrome cbb3 with CcoP2 isoform)

EMD-40645

Single-particle
3.0 Å
EMD-40645 Deposition: 28/04/2023
Map released: 11/10/2023
Last modified: 11/10/2023
Overview 3D View Sample Experiment Validation Volume Browser Additional data Links
Sample Organism: Pseudomonas aeruginosa
Sample: cytochrome bc1-cbb3 supercomplex

Deposition Authors: Di Trani JM , Rubinstein JL
Structure of the bc 1 - cbb 3 respiratory supercomplex from Pseudomonas aeruginosa.
Di Trani JM , Gheorghita AA , Turner M , Brzezinski P , Adelroth P , Vahidi S , Howell PL, Rubinstein JL
(2023) PNAS , 120 , e2307093120 - e2307093120
PUBMED: 37751552
DOI: doi:10.1073/pnas.2307093120
ISSN: 1091-6490
ASTM: PNASA6
Abstract:
Energy conversion by electron transport chains occurs through the sequential transfer of electrons between protein complexes and intermediate electron carriers, creating the proton motive force that enables ATP synthesis and membrane transport. These protein complexes can also form higher order assemblies known as respiratory supercomplexes (SCs). The electron transport chain of the opportunistic pathogen Pseudomonas aeruginosa is closely linked with its ability to invade host tissue, tolerate harsh conditions, and resist antibiotics but is poorly characterized. Here, we determine the structure of a P. aeruginosa SC that forms between the quinol:cytochrome c oxidoreductase (cytochrome bc1) and one of the organism's terminal oxidases, cytochrome cbb3, which is found only in some bacteria. Remarkably, the SC structure also includes two intermediate electron carriers: a diheme cytochrome c4 and a single heme cytochrome c5. Together, these proteins allow electron transfer from ubiquinol in cytochrome bc1 to oxygen in cytochrome cbb3. We also present evidence that different isoforms of cytochrome cbb3 can participate in formation of this SC without changing the overall SC architecture. Incorporating these different subunit isoforms into the SC would allow the bacterium to adapt to different environmental conditions. Bioinformatic analysis focusing on structural motifs in the SC suggests that cytochrome bc1-cbb3 SCs also exist in other bacterial pathogens.
