3x1t

X-ray diffraction
2.81Å resolution

Crystal structure of nucleosome core particle consisting of mouse testis specific histone variants H2aa and H2ba

Released:

Function and Biology Details

Structure analysis Details

Assembly composition:
hetero decamer (preferred)
PDBe Complex ID:
PDB-CPX-117108 (preferred)
Entry contents:
4 distinct polypeptide molecules
1 distinct DNA molecule
Macromolecules (5 distinct):
Histone H3.1 Chains: A, E
Molecule details ›
Chains: A, E
Length: 135 amino acids
Theoretical weight: 15.31 KDa
Source organism: Homo sapiens
Expression system: Escherichia coli
UniProt:
  • Canonical: P68431 (Residues: 2-136; Coverage: 99%)
Gene names: H3C1, H3C10, H3C11, H3C12, H3C2, H3C3, H3C4, H3C6, H3C7, H3C8, H3FA, H3FB, H3FC HIST1H3C, H3FD, H3FF, H3FH, H3FI, H3FJ, H3FK, H3FL, HIST1H3A, HIST1H3B, HIST1H3D, HIST1H3E, HIST1H3F, HIST1H3G, HIST1H3H, HIST1H3I, HIST1H3J
Sequence domains: Core histone H2A/H2B/H3/H4
Structure domains: Histone, subunit A
Histone H4 Chains: B, F
Molecule details ›
Chains: B, F
Length: 102 amino acids
Theoretical weight: 11.26 KDa
Source organism: Homo sapiens
Expression system: Escherichia coli
UniProt:
  • Canonical: P62805 (Residues: 2-103; Coverage: 99%)
Gene names: H4-16, H4/A, H4/B, H4/C, H4/D, H4/E, H4/G, H4/H, H4/I, H4/J, H4/K, H4/M, H4/N, H4/O, H4C1, H4C11, H4C12, H4C13, H4C14, H4C15, H4C16, H4C2, H4C3, H4C4, H4C5, H4C6, H4C8, H4C9, H4F2, H4FA, H4FB, H4FC, H4FD, H4FE, H4FG, H4FH, H4FI, H4FJ, H4FK, H4FM, H4FN, H4FO, HIST1H4A, HIST1H4B, HIST1H4C, HIST1H4D, HIST1H4E, HIST1H4F, HIST1H4H, HIST1H4I, HIST1H4J, HIST1H4K, HIST1H4L, HIST2H4, HIST2H4A, HIST2H4B, HIST4H4
Sequence domains: Centromere kinetochore component CENP-T histone fold
Structure domains: Histone, subunit A
Histone H2A Chains: C, G
Molecule details ›
Chains: C, G
Length: 128 amino acids
Theoretical weight: 13.95 KDa
Source organism: Mus musculus
Expression system: Escherichia coli
UniProt:
  • Canonical: Q8CGP4 (Residues: 2-129; Coverage: 99%)
Gene names: H2ac1, Hist1h2aa
Sequence domains:
Structure domains: Histone, subunit A
Histone H2B type 1-A Chains: D, H
Molecule details ›
Chains: D, H
Length: 126 amino acids
Theoretical weight: 14.14 KDa
Source organism: Mus musculus
Expression system: Escherichia coli
UniProt:
  • Canonical: P70696 (Residues: 2-127; Coverage: 99%)
Gene names: H2bc1, Hist1h2ba, Th2b
Sequence domains: Core histone H2A/H2B/H3/H4
Structure domains: Histone, subunit A
DNA (146-MER) Chains: I, J
Molecule details ›
Chains: I, J
Length: 146 nucleotides
Theoretical weight: 45.05 KDa

Ligands and Environments

2 bound ligands:
No modified residues

Experiments and Validation Details

Entry percentile scores
X-ray source: SPRING-8 BEAMLINE BL41XU
Spacegroup: P212121
Unit cell:
a: 105.771Å b: 109.597Å c: 181.597Å
α: 90° β: 90° γ: 90°
R-values:
R R work R free
0.212 0.21 0.266
Expression system: Escherichia coli
