X-ray diffraction
2.09Å resolution

Structure of bovine endothelial nitric oxide synthase heme domain in complex with (N1-(2-(1H-imidazol-1-yl)pyrimidin-4-yl)-N2-(3- fluorophenethyl)ethane-1,2-diamine

Released:
DOI: 10.2210/pdb4d33/pdb
PDB entry 4d33 coloured by chain, front view.
PDB entry 4d33 coloured by chain, side view.
PDB entry 4d33 coloured by chain, top view.
Source organism: Bos taurus
Primary publication:
Novel 2,4-disubstituted pyrimidines as potent, selective, and cell-permeable inhibitors of neuronal nitric oxide synthase.
Mukherjee P, Li H, Sevrioukova I, Chreifi G, Martásek P, Roman LJ, Poulos TL, Silverman RB
OpenAccess logo J Med Chem 58 1067-88 (2015)
PMID: 25489882

Function and Biology Details

Reaction catalysed:
(1a) 2 L-arginine + 2 NADPH + 2 O(2) = 2 N(omega)-hydroxy-L-arginine + 2 NADP(+) + 2 H(2)O
Biochemical function:
Biological process:
Cellular component:
  • not assigned
Sequence domains:

Structure analysis Details

Assembly composition:
homo dimer (preferred)
Assembly name:
PDBe Complex ID:
PDB-CPX-151510 (preferred)
Entry contents:
1 distinct polypeptide molecule
Macromolecule:
Nitric oxide synthase 3 Chains: A, B
Molecule details ›
Chains: A, B
Length: 443 amino acids
Theoretical weight: 49.62 KDa
Source organism: Bos taurus
Expression system: Escherichia coli BL21(DE3)
UniProt:
  • Canonical: P29473 (Residues: 40-482; Coverage: 37%)
Gene name: NOS3
Sequence domains: Nitric oxide synthase, oxygenase domain
Structure domains:

Ligands and Environments


Cofactor: Ligand HEM 2 x HEM
7 bound ligands:
Ligand H4B 2 x H4B
Ligand 6J0 2 x 6J0
Ligand ACT 2 x ACT
Ligand MTL 2 x MTL
Ligand GOL 2 x GOL
Ligand BME 1 x BME
Ligand ZN 1 x ZN
No modified residues

Experiments and Validation Details

Entry percentile scores
X-ray source: ALS BEAMLINE 8.2.1
Spacegroup: P212121
Unit cell:
a: 56.936Å b: 105.126Å c: 154.388Å
α: 90° β: 90° γ: 90°
R-values:
R R work R free
0.167 0.165 0.21
Expression system: Escherichia coli BL21(DE3)
