5d7l

X-ray diffraction
3.4Å resolution

Function and Biology Details

Structure analysis Details

Assembly composition:
hetero dimer (preferred)
PDBe Complex ID:
PDB-CPX-158331 (preferred)
Entry contents:
4 distinct polypeptide molecules
Macromolecules (4 distinct):
Major histocompatibility complex class I-related gene protein Chains: A, C
Molecule details ›
Chains: A, C
Length: 271 amino acids
Theoretical weight: 31.71 KDa
Source organism: Homo sapiens
Expression system: Escherichia coli BL21(DE3)
UniProt:
  • Canonical: Q95460 (Residues: 23-292; Coverage: 85%)
Gene name: MR1
Sequence domains:
Structure domains:
Beta-2-microglobulin Chains: B, F
Molecule details ›
Chains: B, F
Length: 100 amino acids
Theoretical weight: 11.88 KDa
Source organism: Homo sapiens
Expression system: Escherichia coli BL21(DE3)
UniProt:
  • Canonical: P61769 (Residues: 21-119; Coverage: 100%)
Gene names: B2M, CDABP0092, HDCMA22P
Sequence domains: Immunoglobulin C1-set domain
Structure domains: Immunoglobulins
MAV36 TCR Alpha Chain Chains: D, G
Molecule details ›
Chains: D, G
Length: 203 amino acids
Theoretical weight: 22.58 KDa
Source organism: Homo sapiens
Expression system: Escherichia coli BL21(DE3)
Structure domains: Immunoglobulins
MAV36 TCR Beta Chain Chains: E, H
Molecule details ›
Chains: E, H
Length: 243 amino acids
Theoretical weight: 27.9 KDa
Source organism: Homo sapiens
Expression system: Escherichia coli BL21(DE3)
Structure domains: Immunoglobulins

Ligands and Environments

1 bound ligand:
No modified residues

Experiments and Validation Details

Entry percentile scores
X-ray source: AUSTRALIAN SYNCHROTRON BEAMLINE MX2
Unit cell:
a: 89.28Å b: 222.432Å c: 98.979Å
α: 90° β: 100.15° γ: 90°
R-values:
R R work R free
0.283 0.28 0.337
Expression system: Escherichia coli BL21(DE3)
