5bv1

X-ray diffraction
2.9Å resolution

Crystal Structure of a Vps33-Vps16 Complex from Chaetomium thermophilum

Released:

Function and Biology Details

Structure analysis Details

Assembly composition:
hetero dimer (preferred)
PDBe Complex ID:
PDB-CPX-124027 (preferred)
Entry contents:
2 distinct polypeptide molecules
Macromolecules (2 distinct):
UBC core domain-containing protein Chains: A, C
Molecule details ›
Chains: A, C
Length: 669 amino acids
Theoretical weight: 73.99 KDa
Source organism: Thermochaetoides thermophila DSM 1495
Expression system: Escherichia coli BL21(DE3)
UniProt:
  • Canonical: G0SCM5 (Residues: 139-806; Coverage: 83%)
Gene name: CTHT_0057760
Sequence domains: Sec1 family
Structure domains:
Probable vacuolar protein sorting-associated protein 16 homolog Chains: B, D
Molecule details ›
Chains: B, D
Length: 333 amino acids
Theoretical weight: 37.91 KDa
Source organism: Thermochaetoides thermophila DSM 1495
Expression system: Escherichia coli BL21(DE3)
UniProt:
  • Canonical: G0S6M7 (Residues: 505-671, 673-816; Coverage: 38%)
Gene name: CTHT_0026760
Sequence domains: Vps16, C-terminal region

Ligands and Environments

1 bound ligand:
No modified residues

Experiments and Validation Details

Entry percentile scores
X-ray source: NSLS BEAMLINE X29A
Spacegroup: P21
Unit cell:
a: 79.28Å b: 159.902Å c: 97.394Å
α: 90° β: 90.21° γ: 90°
R-values:
R R work R free
0.215 0.212 0.276
Expression system: Escherichia coli BL21(DE3)
