EMD-10528

Structure of the chaperonin gp146 from the bacteriophage EL (Pseudomonas aeruginosa) in the apo state

EMD-10528

Single-particle
3.45 Å
EMD-10528 Deposition: 05/12/2019
Map released: 22/04/2020
Last modified: 22/05/2024
Overview 3D View Sample Experiment Validation Volume Browser Additional data Links
Sample Organism: Pseudomonas phage EL
Sample: The chaperonin gp146 from the bacteriophage EL (Pseudomonas aeruginosa) in the apo state
Fitted models: 6tmv (Avg. Q-score: 0.335)

Deposition Authors: Bracher A, Wang H
Structure and conformational cycle of a bacteriophage-encoded chaperonin.
Bracher A, Paul SS, Wang H, Wischnewski N, Hartl FU, Hayer-Hartl M
(2020) PLoS One , 15 , e0230090 - e0230090
PUBMED: 32339190
DOI: doi:10.1371/journal.pone.0230090
ISSN: 1932-6203
Abstract:
Chaperonins are ubiquitous molecular chaperones found in all domains of life. They form ring-shaped complexes that assist in the folding of substrate proteins in an ATP-dependent reaction cycle. Key to the folding cycle is the transient encapsulation of substrate proteins by the chaperonin. Here we present a structural and functional characterization of the chaperonin gp146 (ɸEL) from the phage EL of Pseudomonas aeruginosa. ɸEL, an evolutionarily distant homolog of bacterial GroEL, is active in ATP hydrolysis and prevents the aggregation of denatured protein in a nucleotide-dependent manner. However, ɸEL failed to refold the encapsulation-dependent model substrate rhodanese and did not interact with E. coli GroES, the lid-shaped co-chaperone of GroEL. ɸEL forms tetradecameric double-ring complexes, which dissociate into single rings in the presence of ATP. Crystal structures of ɸEL (at 3.54 and 4.03 Å) in presence of ATP•BeFx revealed two distinct single-ring conformational states, both with open access to the ring cavity. One state showed uniform ATP-bound subunit conformations (symmetric state), whereas the second combined distinct ATP- and ADP-bound subunit conformations (asymmetric state). Cryo-electron microscopy of apo-ɸEL revealed a double-ring structure composed of rings in the asymmetric state (3.45 Å resolution). We propose that the phage chaperonin undergoes nucleotide-dependent conformational switching between double- and single rings and functions in aggregation prevention without substrate protein encapsulation. Thus, ɸEL may represent an evolutionarily more ancient chaperonin prior to acquisition of the encapsulation mechanism.
