EMD-22284
Head-Middle module of Mediator
EMD-22284
Single-particle4.2 Å

Map released: 03/03/2021
Last modified: 15/05/2024
Sample Organism:
Chaetomium thermophilum (strain DSM 1495 / CBS 144.50 / IMI 039719),
Chaetomium thermophilum
Sample: Head-Middle module of Mediator
Fitted models: 6xp5 (Avg. Q-score: 0.337)
Deposition Authors: Zhang HQ, Chen DC
Sample: Head-Middle module of Mediator
Fitted models: 6xp5 (Avg. Q-score: 0.337)
Deposition Authors: Zhang HQ, Chen DC
Mediator structure and conformation change.
Zhang H
,
Chen DH
,
Mattoo RUH
,
Bushnell DA,
Wang Y,
Yuan C,
Wang L,
Wang C,
Davis RE,
Nie Y,
Kornberg RD
(2021) Mol Cell , 81 , 1781 - 1788.e4



(2021) Mol Cell , 81 , 1781 - 1788.e4
Abstract:
Mediator is a universal adaptor for transcription control. It serves as an interface between gene-specific activator or repressor proteins and the general RNA polymerase II (pol II) transcription machinery. Previous structural studies revealed a relatively small part of Mediator and none of the gene activator-binding regions. We have determined the cryo-EM structure of the Mediator at near-atomic resolution. The structure reveals almost all amino acid residues in ordered regions, including the major targets of activator proteins, the Tail module, and the Med1 subunit of the Middle module. Comparison of Mediator structures with and without pol II reveals conformational changes that propagate across the entire Mediator, from Head to Tail, coupling activator- and pol II-interacting regions.
