› 6fgx

X-ray diffraction
2.9Å resolution

Crystal structure of the small alarmone synthethase 2 from Staphylococcus aureus bound to AMPCPP

Released:
DOI: 10.2210/pdb6fgx/pdb
PDB entry 6fgx coloured by chain, front view.
PDB entry 6fgx coloured by chain, side view.
PDB entry 6fgx coloured by chain, top view.
Source organism: Staphylococcus aureus
Primary publication:
Structural and mechanistic divergence of the small (p)ppGpp synthetases RelP and RelQ.
Steinchen W, Vogt MS, Altegoer F, Giammarinaro PI, Horvatek P, Wolz C, Bange G
OpenAccess logo Sci Rep 8 2195 (2018)
PMID: 29391580

Function and Biology Details

Reaction catalysed:
ATP + GTP = AMP + guanosine 3'-diphosphate 5'-triphosphate
Biochemical function:
Biological process:
Cellular component:
  • not assigned
Sequence domains:

Structure analysis Details

Assembly composition:
homo tetramer (preferred)
Assembly name:
PDBe Complex ID:
PDB-CPX-197814 (preferred)
Entry contents:
1 distinct polypeptide molecule
Macromolecule:
RelA/SpoT domain-containing protein Chains: A, B
Molecule details ›
Chains: A, B
Length: 237 amino acids
Theoretical weight: 28.09 KDa
Source organism: Staphylococcus aureus
Expression system: Escherichia coli BL21(DE3)
UniProt:
  • Canonical: W8U368 (Residues: 2-230; Coverage: 100%)
Gene names: AC807_2032, AS572_08785, CFN12_13755, CV021_15105, DQV00_06625, E1948_07175, E1948_13295, EIG96_03745, EP54_00695, EQ90_03295, ERS092965_01543, ERS1058648_02233, ERS195417_00150, G0V59_10780, G0Z31_03585, G6W84_03820, G6Y24_11435, GO814_08755, GO942_11055, GQX37_12820, GQX52_00055, GZ156_03445, HT539_09000, M1K003_1970, NCTC13131_00008, NCTC6133_03360, NCTC7972_02139, SAMEA1029519_00536, SAMEA1965892_00646, SAMEA2078260_01114, SAMEA2078588_01184, SAMEA2079512_01269, SAMEA2080344_00628, SAMEA2080909_01293, SAMEA2081063_00952, SAMEA2081779_02747, SAMEA4008452_00926, SAMEA4008575_00779, SAMEA4008601_01652, SAMEA4552975_01927, SAMEA70146418_00228, SAMEA70153168_01185, SAMEA70245418_00278, ywaC, ywaC_1
Sequence domains: Region found in RelA / SpoT proteins
Structure domains: Beta Polymerase, domain 2

Ligands and Environments

2 bound ligands:
Ligand MG 2 x MG
Ligand APC 2 x APC
No modified residues

Experiments and Validation Details

Entry percentile scores
X-ray source: ESRF BEAMLINE ID29
Spacegroup: I4122
Unit cell:
a: 125.862Å b: 125.862Å c: 217.879Å
α: 90° β: 90° γ: 90°
R-values:
R R work R free
0.223 0.223 0.262
Expression system: Escherichia coli BL21(DE3)
